A powerful Wavelength Dispersive X-ray Fluorescence (XRF) system for elemental analysis from B - U.Ī dedicated Small Angle X-ray Scattering system (SAXS) is available for measurements of polymers and other nanomaterials in a variety of sample forms, included liquid dispersed nanoparticles, gels, powders and thin films (GISAXS). The suite currently houses five powder diffractometers, two high resolution diffractometers and two single-crystal diffractometers for small molecule structural solution. The X-ray RTP is located on the 3 rd floor of the new Materials & Analytical Science (MAS) building and is well equipped for the study of the structure of a wide variety of materials including single-crystals, epitaxial thin-films, polycrystalline layers, ceramics and powders under both ambient and non-ambient conditions. For further information and any enquiries regarding the use of these X-ray facilities for industrial work please contact the facilities manager Dr David Walker or visit the Warwick Scientific Services website. Our team are highly knowledgeable and have multi-disciplined expertise. The suite is headed by the academic director, Professor Richard Walton, and the facility manager, Dr David Walker with support from our SAXS specialist, Dr Steven Huband, and our senior technician, Dave Hammond. IV).The X-ray diffraction suite at the University of Warwick is a Research Technology Platform (RTP) offering state-of-the-art X-ray scattering services, primarily for materials research. III), and the evaluation of the system performance and uncertainties (Sec. II), numerous refinements to the experimental setup (Sec. Here, we report details of the implementation at the NIF (Sec. This type of XRD platform has been used to observe new solid–solid phase transitions, the absence of expected phases, and the onset of melt. To probe the crystal structure of compressed materials at such extreme conditions, we have developed and implemented an in situ x-ray diffraction (XRD) platform at the NIF. Using laser-driven ramp compression at the National Ignition Facility (NIF), it is possible to reach pressures up to 5 TPa. The ability to study matter at extreme pressure and temperature conditions is often limited by the ability to create and maintain sufficient volumes of such materials at extreme conditions. These dramatic changes in material properties under pressure have a number of practical consequences, including for the structure and evolution of astrophysical bodies and for various terrestrial applications such as inertial confinement fusion. Examples include severe reduction in the melt temperature, 1,2 1. This experimental platform has been used up to 2 TPa (20 Mbar) to determine the crystal structure, measure the density, and evaluate the strain-induced texturing of a variety of compressed samples spanning periods 2–7 on the periodic table.Īt extreme pressures above a hundred gigapascal (100 GPa = 1 Mbar ≈ 1 × 10 6 atm), core electrons on neighboring atoms begin to interact, and matter has been observed to exhibit a variety of exotic behaviors. Variations in system response over the detector area are compensated in order to obtain accurate line intensities this system response calculation includes a new analytic approximation for image-plate sensitivity as a function of photon energy and incident angle. A new variant of a nonlinear background subtraction algorithm is described, which has been used to observe diffraction lines at signal-to-background ratios as low as a few percent. Analytic expressions are reported for systematic corrections to 2 θ due to finite pinhole size and sample offset. The diffracted signal is recorded on image plates with a typical 2 θ x-ray scattering angle uncertainty of about 0.2° and resolution of about 1°. The quasi-monochromatic x-ray pulses have a mean wavelength selectable between 0.6 Å and 1.9 Å depending on the foil material. Up to two independently timed pulses of x rays are produced at or near the time of peak pressure by laser illumination of thin metal foils.
Pressure history in the sample is determined using high-precision velocimetry measurements. Thin samples are sandwiched between tamper layers and ramp compressed using a gradual increase in the drive-laser irradiance. We report details of an experimental platform implemented at the National Ignition Facility to obtain in situ powder diffraction data from solids dynamically compressed to extreme pressures.
